MicroMax™

MicroMax™ - Superior Microporous Protection with Added Durability for the Toughest Environments

MicroMAX™ is Lakeland premium microporous film laminate Type 5 & 6 coverall.

The fabric structure features an additional unique polyester scrim laminated between the film and PP substrate. This acts as a “rip-stop” and adds strength giving MicroMAX™ the highest tear strength of Type 5 & 6 coveralls available.

MicroMAX™ also features bound seams for additional durability and toughness. The combination of fabric and seams results in a garment ideal for more demanding applications where a more durable suit is required.

Download Lakeland comprehensive Guide to Selection of Type 5 & 6 Coveralls for more effective selection of the best suit for the job. Whether protection, durability or breathability is your priority, Lakeland provide the best options.

MicroMax™ Brand Features

High tear strength – tough and durable for more demanding applications
Superior liquid an dust protection
Anti-Stat Treated per EN 1149
Soft, flexible fabric for comfort - High MVTR for higher comfort level
Lakeland “Super-B” style pattern – ergonomically styled and sized for generous fit and superior freedom of movement

View All MicroMax™ Products

Resources

Documents
Sizing Charts

Catalogs

Ce Type 56 Select Guide In

MicroMax™ Documents

Ce Micro Max Pds In

Ce Size Diagram 2018

Brand Details
Test Data

MicroMax® Specifications

Seam Types: Bound
Materials: Microporous film laminate with strengthening polyester scrim. 68 gsm.
Garment Configurations: Coverall with 3 piece hood, inset sleeves, 2 piece diamond crotch gusset, elasticated hood, waist, cuffs and ankles. Also available in lab coats, overshoes, sleeves etc

Additional Notes

Applications

Dirt, Oil and Grease
Non-hazardous Liquids
Non-hazardous Liquids (Aerosol)
Paint and Hazardous Liquids – Spray
Dry Particle - Aerosols
Paint Booth
Bloodborne Pathogens
Windblade & similar manufacture

Certifications

EN 13982 (Type 5)
EN 13034 (Type 6)
EN 1149-5 (Anti-static)
EN 1073 (radiation contaminated dusts)

MicroMax™ Physical Properties

Physical Property	Test Method	Units	Test Results
Abrasion Resistance	EN 530	Cycles	<500 cycles / Class 2
Burst Strength	ISO 2960	Kilopascals	222.2kPa / Class 3
Flex Cracking Resistance	ISO 7854	Cycles	100,000 Cycles / Class 6
Hydrostatic Head	ISO 811	cm	310cm
Puncture Resistance	EN 863	Newtons	7.2N / Class 1
Resistance to Ignition	EN 13274-4		Pass
Seam Strength	EN 5082	Newtons	110N / Class 3
Tensile Strength - cd	ISO 13934	Newtons	75N / Class 2
Tensile Strength - md	ISO 13934	Newtons	110N / Class 3
Trapezoidal Tear - cd	EN 9073	Newtons	39.5N / Class 2
Trapezoidal Tear - md	EN 9073	Newtons	75.1N / Class 4
Trapezoidal Tear - mean	EN 9073	Newtons	57.3N / Class 3

Physical properties data is based on standard tests required by CE certification designed to allow easy comparison of the strength, durability and robustness of different garments. Lakeland's "Guide to Type 5 & 6 Coveralls" contains easy reference comparison tables of Lakeland garments with main competitors. A glossary with brief explanation of these tests can be found in Lakeland’s “Guide to Chemical Suit Selection”.

MicroMax™ Chemical Penetration Data

Chemical Test	Physical State	Test Results
Butan-1-ol	Liquid	R = Class 3 / P = Class 2
o-Xylene	Liquid	R = Class 3 / P = Class 2
Sodium Hydroxide 10%	Liquid	R = Class 3 / P = Class 3
Sulphuric Acid 30%	Liquid	R = Class 3 / P = Class 3

Penetration is the process by which a liquid (or dust) will pass through the fabric via holes or gaps in its structure. It is generally measure using visual methods and is suitable for garments designed to protect against low hazard chemical such as paints and light cleaning fluids.

Penetration Data shown For CE garments relates to the liquid Penetration/Repellency test EN 6530 (previously EN 368) required by the Type 6 standard EN 13034.
This test, also known as the “Gutter Test”; places a sample of fabric in a “gutter” suspended at 45o. The liquid is dripped onto the fabric and two figures are recorded; the percentage of the liquid that runs off the fabric (the % Repellency), and the percentage of the liquid that penetrates through the fabric (the % Penetration)
Four chemicals may be tested (Sulphuric Acid 30%, Sodium Hydroxide 10%, Butan-1-ol and o-Xylene) and results are classified according to the following tables (found in EN 14325):-
Repellency: Class 1: >70%, Class 2: >80%, Class 3: >90%
Penetration: Class 1: <10%, Class 2: <5%, Class 3: <1%
(Note, The Repellency class thresholds were changed in the 2018 version of the classification standard (EN 14325). The previous thresholds were:
Class 1: >80%, Class 2: >90%, Class 3: > 95%. The explanation given was for reason of statistical uncertainty in results)

The Type 6 standard requires that:-
- For Repellency a Class 3 shall be obtained on at least one of the four chemicals, and
- For Penetration a Class 2 shall be obtained on at least one of the four chemicals
